| Main Technical specifications | unit | QK1313 | QK1319 | QK1322 | QK1327 | QK1335 | QK1343 | QK1352 | |
| Capacities | Swing over bed | mm | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1200 |
Swing over carriage | mm | 350 | 350 | 350 | 610 | 610 | 610 | 710 | |
Tube outside diameter | mm | 30-127 | 50-196 | 50-220 | 100-275 | 100-350 | 270-430 | 300-510 | |
Max. length of workpiece | mm | 1500、3000 | |||||||
Max. length of turning | mm | 1350、2800 | |||||||
Span of guideway | mm | 550 | 550 | 550 | 705 | 755 | 755 | 1100 | |
Max. load of Lathe bed | KG | 3500 | 6000 | ||||||
Quenching hardness | ≤HRC55 | ||||||||
| Spindle | Spindle bore (dia) | mm | φ130 | φ200 | φ225 | φ280 | φ355 | φ440 | φ520 |
Mode of spindle speed | Three-Speed Frequency Conversion①three gears variable frequency/②stepless speed regulation | ||||||||
Range of spindle speed | r/min | 20-800 | 20-450 | 20-450 | 10-300 | 10-260 | |||
Power of main motor | KW | 11 | 18.5 | 22 | 30 | ||||
Size of chuck | φ400/3Jaw Chuck | φ500/3Jaw Chuck | φ500/3Jaw Chuck | φ500/4Jaw Chuck | φ1000/4Jaw Chuck | ||||
| Feed motion | Minimum feed increment of X-/Z-axis | mm | 0.001/0.001 | ||||||
Rapid speeds of X-/Z-axis | mm | 3000/6000 | 4000/5000 | ||||||
Max. travel of X-axis | mm | 300 | 400 | 500 | 600 | ||||
Max. travel of Z-axis | mm | 1350/2850 | |||||||
| Turret | Turret type | V4□240 | V4□280 | V4□300 | |||||
Section of tool shank | mm | 32×32 | 40×40 | ||||||
Turret indexing time | s | 2.5 | 4 | ||||||
Indexing repeatability | mm | 0.008 | 0.010 | ||||||
| Tailstock | Diameter of tailstock quill | mm | 100 | 140 | |||||
Travel of tailstock quill | mm | 250 | 300 | ||||||
Taper hole of tailstock quill | Morse 5 Morse6 | ||||||||
| CNC system | CNC System | Guang shu 980TC3 GSK980TC3(Standard Configuration)Optional:①SINUMERIK 808D/②FANUC Series Oi-TF | |||||||
X-axis motor torque | N.m | 10 | 15 | 22 | |||||
Z-axis motor torque | N.m | 15 | 22 | 30 | |||||
Workpiece accuracy | IT6~7 | ||||||||
Roughness | Ra1.6 | ||||||||
| Packing size | Length (L) | mm | 3800/5300 | 4300/5800 | 5800/7100 | 6000 | |||
Width (W) | mm | 2000 | 2100 | 2200 | 2300 | ||||
Height (H) | mm | 1900 | 2150 | 2260 | 2360 | ||||
Machine weight | kg | 5000/6300 | 9500/11000 | 14000/15800 | 19000 | ||||
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
