| PARAMETER | UNT | CKNC6132 | CKNC6136 | CKNC6140 | CKNC6150 | CKNC6163 | CKNC6180 | CKNC61100 | CKNC61125/1140 |
| MAX.SWING OVER BED | 320 | 360 | 400 | 500 | 630 | 800 | 1000 | 1250/1400 | |
| MAX.SWUBG OVER SLIDE | 200 | 230 | 260 | 350 | 480 | 600 | 850 | ||
| MAX.PROCESSING LENGTH | 360 | 500/750 | 750/1000 | 750/1000/1500 | 1500/3000 | 1500/3000/6000/8000/100000 | |||
| GUIDEWAY WIDTH OF BED | 220 | 350 | 350 | 390 | 550 | 550 | 660/755 | 755/1100 | |
| X AXIS TRAVEL | 170 | 210 | 220 | 260 | 400 | 400 | 520 | 625 | |
| X/Z AXIS RAPID SPEED | 6/8 | 6/8 | 6/8 | 6/10 | 4/7 | 4/7 | 4/7 | 4/7 | |
| X/Z POSITIONING PRECISION | 0.012/0.016 | 0.012/0.016 | 0.012/0.016 | 0.012/0.016 | 0.02/0.03 | 0.02/0.003 | 0.02/0.003 | 0.02/0.03 | |
| X/Z REPOSITIONING PRECISION | 0.008/0.012 | 0.008/0.012 | 0.008/0.012 | 0.008/0.012 | 0.01/0.015 | 0.01/0.015 | 0.01/0.015 | 0.01/00.15 | |
| ELLIPTICITY | 0.01 | ||||||||
| SURFACE ROUGHNESS | Ra1.6 | ||||||||
| SPINDLE SPEED RANGE | 50-3500 | 50-3000 | 50-2500 | 60-200 200-650 650-1600 | 40-125 110-350 290-950 |
15-500 | |||
| SPINDLE HEAD TYPE | A2-5 | A2-6 | A2-6 | C-5/C-8/ D-8 | C11/15 | C11/15 | |||
| DIA.OF SPINDLE THRU-HOLE | 40 | 52 | 56 | 66/82 | 105 | 105 | 130 | 130 | |
| SPINDLE HOLE TAPPER | MT5 | MT6 | MT6 | 105mm.1:20 | 1:20(120mm) | 1:20(120mm) | 1:20(140mm) | 1:20(140mm) | |
| CHUCK | 160(6") | 200(8") | 200(8") | 250(10") | 320(12") | 400(16") | 500(20") | 500(20") | |
| SPINDLE MOTOR POWER | 3.7/5.5 | 5.5 | 5.5 | 7.5 | 11 | 11/15 | 15 | 15 | |
| TOOL HOLDER TYPE | VERTICAL 4 STATIONS (HORIZONTAL6/8 STATIONS) | ||||||||
| TURING TOOL SIZE | mm | 20X20 | 25X25 | 30X30 | 35X35 | ||||
| TAILSTOCK SLEEVE TRAVEL | 90 | 100 | 120 | 150 | 250 | 250 | 250 | 250 | |
| TAILSTOCK SLEEVE DIA. | 46 | 52 | 60 | 75 | 100 | 100 | 100 | 100 | |
| TAILSTOCK SLEEVE TAPE | MT3 | MT4 | MT4 | MT5 | MT5 | MT5 | MT6 | MT6 | |
| N.W | KG | 18000 | 21000 | 24000 | 2600 | 3600 | 3900 | 6000/8500/13500 | |
| DIMENSION | m | 2.1x1.1x1.7 2.35x1.1x1.7 | 2.1x1.7x1.7 2.35x1.7x1.7 | 2.5x1.7x1.7 2.7x1.7x1.7 | 3.5x1.5x1.6 | 3.7x1.9x1.8 | 4.2x2x1.8 4.75x2x1.8 5.75x2x1.8 | ||
The casting wood type of this machine tool adopts aluminum wood combination, resin sand casting, worktable HT300, and the rest are TH250. And after two manual aging treatments, it has good stability, high strength, and stable and reliable accuracy in all a
The casting wood type of this machine tool adopts aluminum wood combination, resin sand casting, worktable HT300, and the rest are TH250. And after two manual aging treatments, it has good stability, high strength, and stable and reliable accuracy in all a
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
The Casting Wood Type Of This Machine ToolAdoptsAluminum Wood Combination, Resin Sand Casting
